Kenwood

NX-5600H

The KENWOOD NX-5600H digital mobile radio deck operates across more than one mode, including NXDN, P25 and analog FM. They are also available with dual remote-control head and multi-band (multi RF deck) control options, making these highly advanced radios ideal for mission-critical users.

Performance Characteristics

Frequency Band:
Low Band

Frequency Range:
39-50 MHz

Power Output:
110W

Number of Channels/Groups/Zones:
1024 Channels / 128 Zones

Channel spacing:
12.5 / 15 / 25 / 30 kHz, 12.5 / 25 kHz Analog
6.25 / 12.5 kHz Digital

Physical Characteristics

Dimensions W x H x D
N/A

Weight (with standard battery)
N/A

Keypad / Keys
No Keypad

Display
No Display

User Environment

Operating temperature
-22°F to +140°F

Mil spec
MIL-STD-810 C/D/E/F/G

IP Standards
IP54/55

Request A Quote

Multi-Digital Operation in NXDN/P25
Support NX-5000 Remote Control Head Options
Multi-RF Deck Configuration Available (Lovband, VHF, 380-470, 450-520, 7&800)
Built-in Micro USB A-B Interface
Horn Alert / Public Address
Built-in GPS Receiver
Built-in Bluetooth® Module
Built-in 56-bit DES Encryption (4 keys programmable by KPG-D1N)
Optional 256-bit AES Encryption
12 Watt Audio Output
DB-25 & Molex 9-pin Accessory Connector
Active Noise Reduction (ANR)
KPG-D1N Windows® FPU
Flash Firmware Upgrading

Cables [+]

	KCT-23M2 DC Cable (75/110W Dash mount)
	KCT-23M4 DC Cable (75/110W Remote mount)
	KCT-71A100 KCT-71A Extended Control Head Cable (up to 100 ft. max.) Note: Please specify exact length at 1ft. increments when ordering. Caution: Extended control head cables exhibit a loss in speaker audio power to the control heads.
	KCT-71A50 KCT-71A Extended Control Head Cable (up to 50 ft. max.) Note: Please specify exact length at 1ft. increments when ordering. Caution: Extended control head cables exhibit a loss in speaker audio power to the control heads.
	KCT-71M2 Remote Control Cable (17 feet)
	KCT-71M3 Remote Control Cable (25 feet)
	KCT-71M4 Remote Control Cable (1.6 feet)
	KCT-77M2 Remote Control Cable for KCH-21RM (17 feet)
	KCT-90USB USB Mobile Cable for SD Card Direct Access Support Note: microSD function requires KWD-5002SD license.
	KCT-91MRS DB25 Cable for Mobile Relay Station (Conventional Only) Note: - Mobile Relay Station requires Multi RF Deck Configuration. The cable requires between Decks.- Built-in GPS and Bluetooth are not available with Mobile Relay Station.

Control Station Accessories [+]

KMC-59C

Control Station Desktop Microphone (8-pin mod. plug)
Note: Compatible with FDMA (analog) and TDMA operations.

KMC-9C

Control Station Desktop Microphone (8-pin mod. plug)

Microphones And Speakers [+]

	KCT-73MIC External Microphone kit w/9.8 ft. cord for Safer Driving
	KCT-74PTT External PTT Switch kit w/9.8 ft cord for Safer Driving
	KES-5 External speaker, 40W max input Note: requires KCT-60M installed.
	KMC-35 MIL-SPEC Standard electret mobile microphone (8-pin mod. plug) - same as supplied
	KMC-36 MIL-SPEC Standard electret mobile microphone with 12-key DTMF (8-pin mod. plug)

Mobile Installation Accessories [+]

	KCT-72 External Accessory Connection Cable for KRK-18HM
	KLF-2 Line Filter (suppresses alternator whine, 25dB, 25A max).
	KMB-36 Mounting Bracket for NX-5000 High Power RF Deck
	KRA-40GM GPS Antenna

Remote Control Kits

	KCH-19M Basic Control Panel
	KCH-20RM Full Featured Remote Control Panel. No Internal Speaker included. KES-5/3 is required.
	KCH-21RM Hand Held Control Head for Long Cable *Requires KCT-77M2 (17 ft.)
	KCH-21RM-S Hand Held Control Head with Short Cable (4 ft.)
	KRK-14HM Control Head Interface Kit for KCH-19M
